OptiX OSN 8800 TN11VA4 4-channel variable optical attenuator unit-- OSN 8800

Functions and Features

The VA4 board is mainly used to adjust optical power and provide power-off protection.

For detailed functions and features, refer to Table 1.

Table 1 Functions and features of the VA4 board

Function and Feature	Description
Basic function	Queries the attenuation and adjust the optical power of four optical signals respectively according to the control command sent by the SCC.
Power-off protection	Supports power-off protection to avoid damage to the corresponding optical receiver caused by too-high optical power when the power supply recovers.
Attenuation range	The variable attenuation ranges between 1.5 dB and 21.5 dB. The resolution is 0.1 dB. NOTE: The maximum inherent insertion loss of the VA4 is 1.5 dB.
Optical-layer ASON	Supported

VA4 Specifications

Specifications include optical specifications, dimensions, weight, and power consumption.

TN11VA4 Optical Specifications

Table 1 lists the optical specifications of the TN11VA4 board.

Table 1 Optical specifications of the TN11VA4 board

Item		Unit	Value
IN-OUT	Inherent insertion loss	dB	<=1.5
IN-OUT	Dynamic attenuation range	dB	20
Adjustment accuracy		dB	1

TN12VA4/TN13VA4 Optical Specifications

Table 2 lists the optical specifications of the TN12VA4/TN13VA4 board.

Table 2 Optical specifications of the TN12VA4/TN13VA4 board

Item

Unit

Value

IN-OUT

Inherent insertion loss

<=1.5

Dynamic attenuation range

Adjustment accuracy

1 (attenuation<=10 dB)

1.5 (attenuation<=15 dB)

1.8 (attenuation>15 dB)

Mechanical Specifications

Dimensions of front panel (H x W x D): 264.6 mm (10.4 in.) x 25.4 mm (1.0 in.) x 220 mm (8.7 in.)
Weight: 1.0 kg (2.2 lb.)

Power Consumption

Board	Typical Power Consumption (W)	Maximum Power Consumption^a (W)
TN11VA4/TN12VA4	8.5	9.4
TN13VA4	6.4	7.0
a: The maximum power consumption is the power consumed by the board when it works normally under the highest ambient temperature.
