Specifications | ZXCTN 608 | ZXCTN 608P | ZXCTN 6120E | ZXCTN 6120S | ZXCTN 6150 | ZXCTN 6180 |
Switching Capacity | 6G | 26G | 32G | 66G | 90G | 100G |
Packet Forwarding Rate | 8.9Mpps | 36.7Mpps | 47.616Mpps | 98.208Mpps | 133.92Mpps | 148.8Mpps |
Number of Service Slots | NA | NA | NA | 3 | 6/7 | 10 |
Main Control Redundancy | NA | NA | NA | NA | 1+1 redundancy | 1+1 redundancy |
Switch Fabric Redundancy | NA | NA | NA | NA | 1+1 redundancy | 1+1 redundancy |
Service Slots | Support GE, FE and E1 interfaces | Support 10GE, GE and FE interfaces | Support 10GE, GE, FE and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces | Support 10GE, GE, FE, STM-1 and E1 interfaces |
VLAN Features | Support 802.1Q-based VLAN, VLAN translation and QinQ |
Link Aggregation | Support LAG link aggregation protection |
Ring Network Protection | Support G.8132 ring network and shared ring network protection |
Link Protection | Support 1+1 and 1:1 modes |
MPLS/MPLS VPN | Support LDP and RSVP-TE protocols; support MPLS L2/L3 VPN |
QOS/ACL | Traffic classification: Support packet classification based on physical interface, VLAN,
802.1p and DSCP.
Traffic policing: Implement CIR, CBS and EIR/EBS and dual token bucket based on
traffic.
Congestion avoidance and management: Support Tail Drop and WRED.
Queue scheduling: Support SP and WRR.
Traffic shaping: Support priority queue-based traffic shaping and port-based
traffic shaping. |
Functions and Features | L2 features: Support Vlan, MAC management, storm suppression, QinQ, port
mirroring, ARP, STP/RSTP/MSTP, 802.1x and DHCP relay.
L3 features: Support static route, OSPF, ISIS and BGP route.
Technical standards: Support MPLS-TP and IP/MPLS technical standards.
OAM: Support BFD, MPLS-TP OAM and Ethernet OAM.
Reliability: Support LSP/PW linear protection, FRR, LAG, and ring network
protection.
Synchronization: Support 1588V2, synchronous Ethernet and differential clock. |
Dimension (W*H*D)mm | 330*43.6*220 | 220*276*79.5 | 482.6*45*199 | 482.6*45*199 | 482.6*88.9*199 | 482.6*130.8*199 |
Height | 1U | NA | 1U | 1U | 2U | 3U |
Power Supply | DC power supply: -48V
AC power supply: 220V | DC power supply: -48V
AC power supply: 220V | DC power supply: -48V
AC power supply: 220V | DC power supply: -48V
AC power supply: 220V | DC power supply: -48V
AC power supply: 220V | DC power supply: -48V
AC power supply: 220V |
Max. Power Consumption | 30W | 90W(with POE) | 50W | 115W | 225W | 340W |
Typical Power Consumption | 25W | 25W | 40W | 70W | 150W | 250W |
Working Environment | -40 ℃~+65 ℃ | -40 ℃~+65 ℃ | -40 ℃~+65 ℃ | -30 ℃~+60 ℃ | -30 ℃~+60 ℃ | -20 ℃~+55 ℃ |
Storage Environment | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ | -40 ℃~+70 ℃ |
Storage Humidity | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% | 5% ~ 95% |
